Chapter 7 Multiservice Switch 7480 installation 79
Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2
Ensure that you plan conforms to the cable specifications for the function
processors in your device. For more information, see the cable assembly
information in NN10600-170 Nortel Networks Multiservice Switch 7400
Hardware Description.
Figure 18
Floor space requirements for Multiservice Switch cabinets
DCP70056
Door
90°
90°
1.5 m
(5 ft)
1 m
(3.3 ft)
1 m
(3.3 ft)
2.1 m
(7 ft)
Cabinet Cabinet Cabinet
Cabinet Cabinet Cabinet
Door
Door
90°
90°
Door
