92 Chapter 10 Alarm hardware installation
NN10600-175 6.1S2
Figure 23
Alarm hardware installation task flow
PP_TASK_1008
Yes
No
No
Yes
at switch
externally
Alarm hardware
installation
Display alarms
at the switch or
externally?
Installing an
external alarm
Installing a rack-
mounted alarm
panel / power and
alarm panel
Installing a
cabinet door alarm
cable for a
Multiservice
Switch
Show alarms from
two Multiservice
Switch 7480s?
Installing a shelf-
interconnect cable
End
Is the Multiservice
Switch 7460 or
Multiservice Switch
7480 in a cabinet?
For procedure page
numbers, see
Task flow navigation
below
