14 LCD-160 P/N 51850:A 09/26/2003
Section 4 Hardware
This section is intended as a basic inventory of components that can be used with the LCD-160.
4.1 Backboxes
These backboxes provide a surface or semi-flush mount enclosure for remote mounting. Use with 1/2”
conduit in the provided knockouts. See Table 4.1 for dimensions.
ABS-2D/ABS-2DR A surface or semi-flush enclosure for remote mounting. Mounts an LCD-160
directly to the enclosure’s hinged dress plate. The “D” version is black and slightly deeper. The ABS-
2D and ABS-2DR will not support the installation of the Annunciator Key Switch or the Annunciator
Phone Jack for Firefighters' Telephone. A trim ring option is available for semi-flush mounting. Not for
use in Canadian applications.
ABS-4D/ABS-4DR A surface or semi-flush enclosure for remote mounting. Mounts an LCD-160 and
two annunciators directly to the enclosure’s hinged dress plate. This backbox will not support the
installation of the Annunciator Key Switch or the Annunciator Phone Jack for Firefighters' Telephone.
ABF-2B A flush enclosure for remote mounting. Mounts an LCD-160 directly to the enclosure’s dress
plate. Not for use in Canadian applications.
ABF-4B A flush enclosure for remote mounting. Mounts an LCD-160 and two annuciators directly to
the enclosure’s dress plate.
CAB-4 Series Cabinet A surface or semi-flush enclosure for mounting one to four rows of equipment
plus batteries (up to two 25AH batteries). There are four different sizes available. The separately
ordered doors can be mounted on the left or the right side of the cabinet; reversible hinges are provided
so that this choice can be made in the field. Doors open a full 180 degrees and have locks. A trim ring
option is available for semi-flush mounting.
External measurements for each cabinet size are provided below. Refer to CAB-3/CAB-4 Series Cabinet
Installation Document (shipped with your cabinet) for specific mounting drawings and dimensions.
Table 4.1 Backbox Sizing Guide
Part
Number Height Width Depth Color
Optional
Trim Ring
ABS-2D
ABS-2DR
Box: 12.00" (30.48 cm.)
Door: 12.00" (30.48 cm.)
Box: 12.00" (30.48 cm.)
Door: 12.00" (30.48 cm.)
Box: 3.797" (9.644 cm)
Door: 1.250" (3.175 cm.)
Red, Black TR-ABS2D
ABS-4D
ABS-4DR
Box: 11.97" (30.40 cm)
Door: 11.97" (30.40 cm)
Box: 19.87" (50.47 cm)
Door: 19.87" (50.47 cm)
Box: 3.5" (8.89 cm)
Door: 1.25" (3.18 cm)
Red, Black N/A
ABF-2B Box: 9.938" (25.24 cm)
Door: 11.0" (27.94 cm)
Box: 9.188" (20.80 cm)
Door: 10.375" (26.35 cm)
Box: 3.750" (9.53 cm)
Door: 0.75" (1.9 cm)
Black N/A
ABF-4B Box: 9.937" (25.240 cm) Box: 17.750" (45.085 cm) Box: 2.500" (6.350 cm) Black N/A
CAB-4 Series (without doors)
A-Size
(1 row)
20.125 in (51.12 cm) 24.125 in (61.28 cm) 5.218 in (13.25 cm) TR-A4
B-Size
(2 rows)
28.625 in (72.70 cm) 24.125 in (61.28 cm) 5.218 in (13.25 cm) TR-B4
C-Size
(3 rows)
37.250 in (94.62 cm) 24.125 in (61.28 cm) 5.218 in (13.25 cm) TR-C4
D-Size
(4 row)
45.875 in (116.52 cm) 24.125 in (61.28 cm) 5.218 in (13.25 cm) TR-D4
