LCD-160 P/N 51850:A 09/26/2003 45
Service Screens Screen Displays
Download Bootloader Screen
This screen is displayed during bootloader downloads. Downloading is initiated at the FACP. The
progress meter shows the progress of the current download.
Figure 30 Download Bootloader Screen
Download Strings Screen
This screen is displayed during strings downloads. Downloading strings is initiated at the FACP.
The progress meter shows the progress of the current download.
Figure 31 Download Strings Screen
TROUBLE
LOADING..NO SERVICE
A01
LCD-160 BOOTLOADER
LCD-160 DOWNLOAD MENU
DO NOT POWER OFF!!!
UPDATING LCD-160 BOOTLOADER
DOWNLOADING...
76%
TROUBLE
LOADING..NO SERVICE
A01
LCD-160 BOOTLOADER
LCD-160 DOWNLOAD MENU
UPDATING LCD-160 STRINGS
DOWNLOADING...
76%
