Notifier XPIQ User Manual

Switch and Jumper Settings Installation
XPIQ PN 51013:C 7/01/03 59
Local Address Assignments
The following tables describe the speaker zone addressing for Canadian Dual Stage mode. In
each table, B designates the starting address which is set by using switches SW1 and SW3 on
the XPIQ-SLI. The starting address is dedicated to the general trouble function.
Operation is as follows:
✓ Activation of Page points at any time causes the respective amplifier and speaker circuit to
activate using the voice riser as the input. These points have the highest priority
✓ Activation of Evacuate points at any time causes the respective amplifier and speaker
circuit to activate with the Stage 2 tone as the input. This takes priority over the Stage 1
Alert
✓ Activation of Alert points causes the respective speaker circuits to activate with the Stage
1 tone
Table 2.20 Two Speaker Zones (1:1 Backup Amplifiers)
Speaker Zone 1 Speaker Zone 2
PAGE (XPIQ-AIB1
Input)
B + G + 1 B + G + 2
EVACUATE (XPIQ-MB
Evacuate Tone Generator)
B + G + 3 B + G + 4
ALERT (XPIQ-MB
Alert Tone Generator)
B + G + 5 B + G + 6
Table 2.21 Three Speaker Zones (3:1 Backup Amplifier)
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3
PAGE (XPIQ-AIB1
Input)
B + G + 1 B + G + 2 B + G + 3
EVACUATE (XPIQ-MB
Evacuate Tone Generator)
B + G + 4 B + G + 5 B + G + 6
ALERT (XPIQ-MB
Alert Tone Generator)
B + G + 7 B + G + 8 B + G + 9
Table 2.22 Four Speaker Zones (No Backup Amplifiers)
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
PAGE (XPIQ-AIB1
Input)
B + G +1 B + G + 2 B + G + 3 B + G + 4
EVACUATE (XPIQ-MB
Evacuate Tone Generator)
B + G + 5 B + G + 6 B + G + 7 B + G + 8
ALERT (XPIQ-MB
Alert Tone Generator)
B + G + 9 B + G + 10 B + G + 11 B + G + 12
