Installation Switch and Jumper Settings
58 XPIQ PN 51013:C 7/01/03
2.6.1.2 Canadian Dual Stage With XPIQ Generated Stage 1 and Stage 2 Tones
The Canadian Dual Stage mode of operation involves automatic FACP activated change from
Stage 1 (Alert) to Stage 2 (Evacuate). A central AMG-1/E and control panel ACS annunciator
provide microphone paging, using only a single voice riser. For this application, the XPIQ
uses a single channel XPIQ-AIB1. The number of addresses used by the XPIQ is the same as
for a three channel system. Stage 1 Alert is a 20 PPM (Pulse Per Minuter) tone generated
locally on the XPIQ which uses channel 3 addresses. Stage 2 Evacuate is an XPIQ generated
temporal tone tone which uses channel 2 addresses. The highest priority paging channel uses
channel 1 addresses. There is no synchronization of tones between speaker zones from any
two XPIQs. If synchronization is required, it is necessary to use an XPIQ-AIB4 for a three
channel system. Program options are as follows:
• Change Temporal to steady tone
• Change Temporal to 120 PPM
Table 2.17 Four Channels, Two Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2
Channel 2 B + G + 3 B + G + 4
Channel 3 B + G + 5 B + G + 6
Channel 4 B + G + 7 B + G + 8
F = 0, M = 0
Table 2.18 Four Channels, Three Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2 B + G + 3
Channel 2 B + G + 4 B + G + 5 B + G + 6
Channel 3 B + G + 7 B + G + 8 B + G + 9
Channel 4 B + G + 10 B + G + 11 B + G + 12
F = 0, M = 0
Table 2.19 Four Channels, Four Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2 B + G + 3 B + G + 4
Channel 2 B + G + 5 B + G + 6 B + G + 7 B + G + 8
Channel 3 B + G + 9 B + G + 10 B + G + 11 B + G + 12
Channel 4 B + G + 13 B + G + 14 B + G + 15 B + G + 16
F = 0, M = 0
