Notifier XPIQ User Manual

Switch and Jumper Settings Installation
XPIQ PN 51013:C 7/01/03 57
Table 2.13 Three Channels, Two Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2
Channel 2 B + G + 3 B + G + 4
Channel 3 B + G + 5 B + G + 6
Channel 4
F = 0, M = 0
Table 2.14 Three Channels Three Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2 B + G + 3
Channel 2 B + G + 4 B + G + 5 B + G + 6
Channel 3 B + G + 7 B + G + 8 B + G + 9
Channel 4
F = 0, M = 0
Table 2.15 Three Channels, Four Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2 B + G + 3 B + G + 4
Channel 2 B + G + 5 B + G + 6 B + G + 7 B + G + 8
Channel 3 B + G + 9 B + G + 10 B + G + 11 B + G + 12
Channel 4
F = 0, M = 0
Table 2.16 Four Channels, Single Speaker Zone
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1
Channel 2 B + G + 2
Channel 3 B + G + 3
Channel 4 B + G + 4
F = 0, M = 0
