Installation Switch and Jumper Settings
56 XPIQ PN 51013:C 7/01/03
Table 2.9 Two Channels, Two Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2
Channel 2 B + G + 3 B + G + 4
Channel 3
Channel 4
F = 0, M = 0
Table 2.10 Two Channels, Three Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2 B + G + 3
Channel 2 B + G + 4 B + G + 5 B + G + 6
Channel 3
Channel 4
F = 0, M = 0
Table 2.11 Two Channels, Four Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2 B + G + 3 B + G + 4
Channel 2 B + G + 5 B + G + 6 B + G + 7 B + G + 8
Channel 3
Channel 4
F = 0, M = 0
Table 2.12 Three Channel, Single Speaker Zone
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1
Channel 2 B + G + 2
Channel 3 B + G + 3
Channel 4
F = 0, M = 0
To Next Page
