Notifier XPIQ User Manual

Programming Panel Programming
68 XPIQ PN 51013:C 7/01/03
3.7 Panel Programming
The XPIQ must be programmed at the FACP with Software Type IDs that are panel-specific. Refer
to the tables belowTable 3.1 for appropriate codes.
Table 3.1 Table 1 FACP Software Type IDs and Label Information, Part 1
Address
Point
Group
1
Point Type
Module
Type
NFS-3030 VeriFire for NFS-3030 and NFS-640
Label examples
Type Code
Label
4
FlashScan Type
4
Type Code
Label
4
FlashScan Type
4
B
Base Address
Monitor Module
Monitor AUDIO SYSTEM XPIQ GEN MON AUDIO SYSTEM XPIQ TROUBLE
XPIQ SYSTEM
TROUBLE
G
Optional separate
troubles for AC fail,
battery fail and earth
fault (required in
Canada)
Monitor AUDIO SYSTEM
XPIQ AC MON
XPIQ BATT MON
XPIQ EF MON
AUDIO SYSTEM
XPIQ AC
XPIQ BATTERY
XPIQ GND FLT
XPIQ AC FAIL
XPIQ BAT FAIL
XPIQ E FAULT
S
Speaker/channel
control points
Control SPEAKER XPIQ SPKR SPEAKER XPIQ SPEAKER
Note 2
PAGE FLOOR1
PAGE FLOOR 2
EVAC FLOOR 1
EVAC FLOOR 2
ALERT FLOOR 1,
ALERT FLOOR 2.
F
Firefighter telephone
points
or
strobe (NAC) circuits
Control
TELEPHONE
CONTROL
XPIQ TELE
XPIQ NAC
TELEPHONE
CONTROL
XPIQ TELEPHONE
XPIQ STROBE
Note 3
TELEPHONE FLOOR 1
STROBES FLOOR 1
M
Optional background
music control point
Control AUDIBLE CKT XPIQ BGND AUDIBLE CKT XPIQ MUSIC BACKGROUND MUSIC
Notes:
1. Refer to the addressing chapter in the addressing section of the XPIQ manual for more information on these groups.
2. The label should describe audio content and speaker zone. The example shown in the table is for a three-channel (channel 1 = PAGE,
channel 2 = EVACUATE, channel 3 = ALERT), two-zone (speaker zone 1 = FLOOR 1, speaker zone 2 = FLOOR 2 ) system.
3. Short trouble on telephone zones may be indicated as TROUBLE OPEN.
4. Autoprogramming assigns these values with the following exception: for the strobe (NAC) circuits in Address Point Group F, the
NFS-640 assigns the Panel Type ID “CONTROL”, then presents choices from which the programmer should select one of these four:
STROBE CKT, HORN CIRCUIT, BELL CIRCUIT, AUDIBLE.
