Notifier XPIQ User Manual

Programming Programming the XPIQ
64 XPIQ PN 51013:C 7/01/03
3.6.3.1 Audio Selection Setup
Source
The source Audio Selection Setup screen allows the programmer to configure the XPIQ for one
to four audio channels with or without backup audio. The audio source selection for audio
channel 1 will determine the available audio sources for channels 2 through 4 as described in
the following table:
Backup Tone Source
A backup tone source can be selected to take over upon failure of the primary audio source.
The primary audio source selection for each channel will determine the available backup tone
source.
Tone Chip Tone Selection
The tone selection can be made for Tone Chip 1 (Tone Generator 1) and Tone Chip 2 (Tone
Generator 2) by clicking the corresponding Tone Chip window to display a pull-down window.
Select the tone by clicking the desired choice within the window.
3.6.3.2 Speaker Zone Info Screen
This screen is used to configure the quantity and type of speaker circuits connected to the XPIQ.
Number of Speaker Zones
Enter the total number of speaker circuits (1 - 4) for the XPIQ
Speaker Wiring Type
Select either Class A or Class B wiring by clicking the switch illustration in this screen.
Selected Audio Source Available Audio Sources
Channel 1 Channel 2 Channel 3 Channel 4
Tone Generator 1
(evacuation)
Tone Generator 2
(alert)
None None
AIB-1 Tone Generator 1
(evacuation)
Tone Generator 2
(alert)
None
AIB-4 (Input 1) AIB-4 (Input 2) AIB-4 (Input 3) AIB-4 (Input 4)
Primary Audio Source Backup Audio Source
Channel 1
Tone Generator 1 Tone Generator 2
AIB-1 Tone Generator 1 or 2
AIB-4 (Input 1) Tone Generator 1 or 2
Channel 2
Tone Generator 1 Tone Generator 2
Tone Generator 2 None
AIB-4 (Input 2) Tone Generator 1 or 2
Channel 3
Tone Generator 2 None
AIB-4 (Input 3) Tone Generator 1 or 2
Channel 4 AIB-4 (Input 4) Tone Generator 1 or 2
