Notifier XPIQ - Page 55

Switch and Jumper Settings Installation
XPIQ PN 51013:C 7/01/03 55
Table 2.5 Single Channel, Two Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2
Channel 2
Channel 3
Channel 4
F = 0, M = 0
Table 2.6 Single Channel, Three Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2 B + G + 3
Channel 2
Channel 3
Channel 4
F = 0, M = 0
Table 2.7 Single Channel, Four Speaker Zones
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1 B + G + 2 B + G + 3 B + G + 4
Channel 2
Channel 3
Channel 4
F = 0, M = 0
Table 2.8 Two Channels, Single Speaker Zone
Speaker Zone 1 Speaker Zone 2 Speaker Zone 3 Speaker Zone 4
Channel 1 B + G + 1
Channel 2 B + G + 2
Channel 3
Channel 4
F = 0, M = 0
