MCTRL600 Independent Controller
Specifications
2 Features
www.novastar.tech
2
2 Features
2.1 Features

1 × DVI input

1 × HDMI 1.3 input

1 × audio input

1 × light sensor connector

Supports resolutions up to 1920×1200@60Hz and downward compatibility.

4 ×RJ45Gigabit Ethernet outputs, each up to 650,000 pixels

1 × type-B USB control port

UART IN and UART OUT control ports for device cascading

Supports the new generation of NovaStar calibration technology, which is fast
and efficient.

Supports a variety of video formats, as described in Figure 2-1.
Note:
Only one input source can be selected the same time and it defaults to HDMI.
2.2 Video Formats
Figure 2-1 Video formats
Input Connector
Bit Depth
Sampling Format
Maximum Input Resolution
HDMI 1.3
8-bit
RGB 4:4:4
1920×1200@60Hz
10-bit/12-bit
1440×900@60Hz
DVI
8-bit
1920×1200@60Hz
10-bit/12-bit
1440×900@60Hz
