NovaPro HD User's Manual
www.novastar.tech -43-
are components with high voltage inside the controller, please DO NOT maintain it by
yourself for the sake of your safety.
11 Technical Specifications
Inputs
Port
Qty
Description
CVBS
1
PAL/NTSC
VGA
1
VESA standard
DVI
1
VESA standard (supporting 1080i input), supporting
HDCP
HDMI
1
EIA/CEA-861 standard, in accordance with HDMI-
1.3standard, supporting HDCP
DP
1
VESA standard
3G-SDI
1
480i、576i、720p、1080i/p（3G SDI）
Outputs
Port
Qty
Description
DVI LOOP
1
DVI loop output, consistent with DVI input connector
SDI LOOP
1
SDI loop output, consistent with SDI input connector
