LED Output
4
4 Gigabit Ethernet outputs. Only Ethernet port 1
supports audio output. When the multifunction card is
connected for audio decoding, the multifunction card
must be connected to the Ethernet port 1.
Maximum horizontal resolution is 3840 pixels.
Maximum vertical resolution is 1920 pixels.
OPT Output
4
4 optical fiber connectors for long-distance
transmission
Monitor
2
DVI and HDMI connectors for output image
monitoring DVI and HDMI connectors output the
same image.
Control Interface
Port
Qty
Description
USB
2
Upper computer control interface
RJ45
1
Multi-units communication interface
DMX
1
Connected to all kinds of control interfaces that
support DMX512 interface protocol.
Overall Specifications
Input power
AC 100-250V, 50/60Hz
Overall power consumption
30 W
