NovaPro HD User's Manual
www.novastar.tech -8-
Fig. 4-2 Oversized Video Source Loading Scheme (4K)
Cascade Control Signal Connection
Fig. 4-3 Cascade Control Signal Connection
5 Description of Operation Modes
NovaPro HD is not only powerful in functions but also easy to use. It supports three
operating modes for users to choose in different occasions.
Mode 1: Machine operation. All operations can be completed by a knob and a button
on NovaPro HD without PC.
Mode 2: Web operation. Suitable for the situation when NovaPro HD and control
computer are in the same LAN. Open up a browser on control computer and enter
the IP of NovaPro HD to log in control page.
