MCTRL600 Independent Controller
Specifications
3 Appearance
www.novastar.tech
4
Connector
Connector
Name
Description
HDMI IN

HDMI 1.3 compliant

Resolution up to 1920×1080@60Hz and downward
compatible

Custom resolutions supported:
Resolution with maximum width: 3840×600@60Hz
Resolution with maximum height: 800×2560@60Hz

Support HDCP.
AUDIO
Audio input connector
Output
RJ45 × 4

4 RJ45 Gigabit Ethernet outputs

Maximum loading capacity of a single Ethernet port:
650,000 pixels

Support redundancy between Ethernet ports.
Function
LIGHT
SENSOR
Connect to light sensor to monitor ambient brightness to
realize automatic screen brightness adjustment.
Control
USB
USB control port for connecting to PC
UART IN
Input port for cascading devices
UART OUT
Output port for cascading devices. Up to 20 controllers
can be cascaded.
Power
AC 100V~240V-50/60Hz
