NovaPro HD User's Manual
www.novastar.tech -4-
- Flashing slowly: There is no video signal.
- Breathing: One or more Ethernet ports are in hot backup mode.
Red indicator: Indicates device power status.
③: Input source buttons and indicators.
Press the input source button to set the input source for main picture. Hold down
the button to set the input source for PIP. You can view the operation result on the
operation screen during setting.
The indictor is blue by default. It turns to green when the current input source is
selected.
④：Operation screen (Please see details in the subsequent Chapter: Main
Interface).
⑤：Knob: Enter by pressing the knob and select or adjust by turning the knob.
⑥：ESC: Exit current operation or option.
⑦：BLK: LED Display is blank screen. Indicator light is blue by default after power
on and it turns green when BLK is enabled;
FRZ: Images on LED Display are frozen. Indicator light is blue by default after
power on and it turns green when enabled;
PIP: Display PIP. Indicator light is blue by default after power on and it turns green
when enabled;
⑧: Type A female interface is USB interface to connect U disk to import
configuration file or update programs.
Type B female interface is USB control interface to connect PC for communication.
