C.1 OEM7700 Performance Specifications
All specifications subject to GNSS system characteristics.
Position Accuracy
1
Single point
L1 only 1.5 m RMS
L1/L2 1.2 m RMS
NovAtel
CORRECT
SBAS
2
60 cm RMS
DGPS 40 cm RMS
PPP
3
,
4
TerraStar-L
TerraStar-C
40 cm RMS
4 cm RMS
RTK 1 cm + 1 ppm RMS
Signals Tracked
GPS L1 C/A, L1C, L2C, L2P, L5
GLONASS L1 C/A, L2C, L2P, L3, L5
5
BeiDou B1, B2, B3
Galileo E1, E5 AltBOC, E5a, E5b, E6
6
IRNSS L5
7
SBAS L1, L5
QZSS L1 C/A, L1C, L2C, L5, L6
L-Band Up to 5 channels
8
Time to First Fix
Hot: <26 s (Almanac and recent ephemeris saved and approximate position
and time entered)
Cold: <46 s (No almanac or ephemeris and no approximate position or time)
Table 31: OEM7700 Receiver Performance
1
Typical values. All position and velocity RMS values are based on Horizontal position accuracy. Performance
specifications are subject to GPS system characteristics, U.S. DOD operational degradation, ionospheric and
tropospheric conditions, satellite geometry, baseline length and multipath effects.
2
GPS-only.
3
Requires a TerraStar subscription which is available direct from NovAtel www.novatel.com/products/novatel-
correct-ppp.
4
Performance dependent on local observing conditions.
5
Although hardware capable, GLONASS L5 is currently not available.
6
Although hardware capable, Galileo E6 is currently not available.
7
Although hardware capable, IRNSS L5 is currently not available.
8
Currently the receiver can track up to 3 L-Band channels.
