Chapter 5 Ethernet Configuration
OEM7 Installation and Operation User Manual v1 79
NovAtel Connect version 2.0 or greater is required for OEM7 receivers.
Download the latest NovAtel Connect PC Utilities suite of software and
documentation, including NovAtel Connect from
www.novatel.com/support/info/documents/809.
3.
Enable the Ethernet port on the receiver by entering:
ETHCONFIG ETHA AUTO AUTO AUTO AUTO
4.
Assign the TCP/IP port number used for the connection by entering:
ICOMCONFIG ICOM1 TCP :2000
5.
Assign the receiver IP address, subnet mask and default gateway by entering:
IPCONFIG ETHA STATIC 192.168.74.10 255.255.255.0 192.168.74.1
The command assigns the following values to the OEM7 receiver:
IP address = 192.168.74.10
Subnet mask = 255.255.255.0
Gateway = 192.168.74.1
These settings are examples only. The settings appropriate to your system may
be different.
6.
Save the new Ethernet settings by entering:
SAVEETHERNETDATA
7.
Log the IPCONFIG command and confirm the TCP/IP configuration by entering:
LOG IPCONFIG ONCE
8.
Configure your computer with a static IP address.
Refer to Static IP Address Configuration—Windows 7 below.
5.2.2 Static IP Address Configuration—Windows 7
Follow these steps to set up a static IP address on a computer:
1.
Click Start | Control Panel.
2.
Click Network and Sharing Center.
3.
Click the Local Area Connection link.
The Local Area Connection Status window appears.
4.
Click the Properties button.
The Local Area Connection Properties window appears.
5.
Select Internet Protocol Version 4 (TCP/IPv4) and then click the Properties button.
The Internet Protocol Version 4 (TCP/IPv4) Properties window appears.
6.
Click the Use the Following IP Address radio button, then enter the IP address, Subnet
mask and Default gateway for the Ethernet port on the computer.
