Chapter 5 Ethernet Configuration
OEM7 Installation and Operation User Manual v1 83
procedure to the receivers.
For information about establishing a connection using NovAtel Connect, refer to
the Help within NovAtel Connect.
NovAtel Connect version 2.0 or greater is required for OEM7 receivers.
Download the latest NovAtel Connect PC Utilities suite of software and
documentation, including NovAtel Connect from
www.novatel.com/support/info/documents/809.
3.
Connect the power cables to both of the OEM7 receivers and apply power to the receivers.
4.
Connect the Ethernet cables to the Ethernet ports on both OEM7 receivers.
5.
Establish an Ethernet connection, either static or dynamic configurations. Refer to Static IP
Address Configuration on page77 or Dynamic IP Address Configuration on page80 for more
information.
6.
Send the following commands to each receiver either through serial or USB ports:
Base:
FIX POSITION <lat> <long> <height>
INTERFACEMODE ICOM1 NONE RTCA off
LOG ICOM1 RTCAOBS2 ONTIME 1
LOG ICOM1 RTCAREF ONTIME 10
LOG ICOM1 RTCA1 ONTIME 5
SAVECONFIG
Rover:
ICOMCONFIG ICOM1 TCP <base ip address>:<base port #>
INTERFACEMODE ICOM1 RTCA NONE OFF
LOG BESTPOSA ONTIME 1 (optional)
SAVECONFIG
Use the BESTPOS log to confirm that the OEM7 rover is in RTK mode.
5.5 Large COM Port Data Throughput
For high data rate Ethernet logging using TCP/IP, disable Windows Delayed Ack Algorithm (DAA)
for complete data logging. If you do not disable DAA, there will be data gaps due to the Windows
Ethernet buffer.
If done incorrectly, changing the Windows Registry may impair the operation of the
computer. Editing the Windows Registry is for advanced Microsoft Windows users
only.NovAtel Inc. is not able to provide any technical support for any actions taken
regarding information found in Microsoft’s Knowledge Base.
