Chapter 3 OEM7 Receiver Operation
OEM7 Installation and Operation User Manual v1 53
Figure 21: STEADYLINE UAL - Out of Bounds Example
A The position type is OPERATIONAL.
Higher accuracy corrections are lost. The receiver changes to a lower accuracy solution.
STEADYLINE operates in Maintain mode while solution accuracy remains within the Operational
limit.
B The solution accuracy exceeds the operational limit. The position type changes to WARNING.
The STEADYLINE mode changes from Maintain to Prefer Accuracy.
C The solution accuracy exceeds the warning limit. The position type changes to OUT_OF_BOUNDS.
STEADYLINE is disabled.
3.8 Enabling SBAS Positioning
OEM7 family receivers are capable of SBAS positioning. This positioning mode is enabled using
the SBASCONTROL command:
sbascontrol enable auto
When the command is entered, the OEM7 family card automatically tracks the SBAS that is oper-
ating in the region (e.g., WAAS or EGNOS) and applies the corrections from the service. On a
simulator, leave the test mode parameter off or specify NONE explicitly. For more on SBAS,
refer to application note APN-051 Positioning Modes of Operation (additional Application Notes
available at www.novatel.com/support/).
3.9 Enabling NovAtel CORRECT with PPP
L-Band equipped receivers can achieve sub-metre position accuracy using correction data
received from geostationary satellites. To use the L-Band corrections, an L-Band-capable
receiver model and antenna are required (refer to our web site www.nova-
tel.com/products/gnss-antennas for information on NovAtel L-Band-capable antennas).
For more information on L-Band positioning, refer to:
l
NovAtel Application Notes: APN-061 NovAtel CORRECT with TerraStar or APN-062 NovAtel
CORRECT with Veripos (service dependent) available from www.nova-
tel.com/support/search/items/Application%20Note
l
the OEM7 Commands and Logs Reference Manual (OM-20000169) for log/command details
and/or
