Chapter 2 Installation of OEM7 Family Receiver Cards
OEM7 Installation and Operation User Manual v1 22
l
Mounting of external connectors
l
Protection from hostile physical environments (rain, snow, sand, salt, water, extreme tem-
peratures, etc)
The OEM Integrator is responsible for ensuring compliance of the final
product with the regulatory bodies for those intended markets.
l
Protection from ESD (see Electrostatic Discharge (ESD) Practices on page188)
l
Location to securely mount the receiver using screws
2.7.1 Planning the Mount Location
When planning the mount location for the OEM7 receiver, ensure there is enough room for the
card. There is an area around the card, called a keep-out zone, where other components in the
enclosure do not intrude. This keep-out zone is intended to prevent other components in the
enclosure from interfering with, or damaging, the OEM7 receiver. For diagrams of the exact
dimensions and keep-out zones for each OEM7 receiver card, see:
l
OEM719 Mechanical Specifications on page113
l
OEM729 Mechanical Specifications on page133
l
OEM7700 Mechanical Specifications on page153
OEM7 receivers are not directional in nature and can be mounted in any orientation.
2.7.2 Board to Board Spacing
A minimum amount of space is required between the OEM7 receiver and the interface or system
board the receiver connects to. Refer to the following table for the minimum and suggested spa-
cing.
OEM7
Receiver
Antenna Con-
nector Type
Minimum
Spacing
Suggested
Spacing
Notes
OEM719 MCX straight 11.00mm 12.00 mm
Mounting rails are available from
NovAtel.
See Table 1: NovAtel Mounting Rails on
page26 for the rails available.
OEM719A MCX right angle 7.00 mm
7.00 mm
10.00 mm
12.00 mm
OEM719B MMBX straight 7.00 mm
7.00 mm
10.00 mm
12.00 mm
OEM7700 MMBX straight 7.00 mm
7.00 mm
10.00 mm
