en-938821/2 5 - 59
CNC Operation
5
Case of machine error and programme resumption
Requirements
Programme interrupted in single step, automatic or dryrun mode. The fault indicator is displayed in the status window
(see 3.1.3) and an error message is displayed in the dialogue window of the information, programme and current
position pages, e.g.:
error 32 Block N150
HOME error/Slide already on origin switch
Actions
For messages with more than one line, display the complete message. ☞
HELP
by pressing:
Analyse the message and the cause of the error.
REMARK Such errors generally require the intervention of maintenance personnel.
Reset the machine. ☞
The RESET indicator and end of part programme indicator M02 are displayed momentarily and the fault indicator is
cleared from the status window (see 3.1.3). The error message is cleared and the "INCYC", "CYHLD" and "AXRCL"
indicators disappear from the status window (if they were present).
Correct the error if the cause was clearly identified.
After correcting the error, machining can be resumed:
- at the beginning of the programme (see 5.4.3) or at the specified block (see 5.5.1.5)
- in single step (SINGLE), automatic (AUTO) or dryrun (DRYRUN) mode (see 5.4.3.2).
If the fault persists, call the maintenance department of the company or Num customer support.
