Operator-Accessible Maintenance
8.8.7.1 Unloading Protected Programmes for Copy on Other Systems
Requirements
CNC connected to the peripheral (See C.2).
Peripheral ready to receive binary data (See peripheral manual).
CNC transmission baud rate (See 8.3) conforming to the peripheral reception baud rate.
Unloading dialogue line displayed (See 8.8.7).
Programmes present in the protected area.
Actions
Saving programmes individually Backing up the complete zone
Enter Enter "%∗"
"[Programme No.]" ☞ ☞
(e.g. "1.2").
If there is a password, display of the message:
ENTER YOUR PASSWORD
Enter the password. ☞
Display of the message:
UNLOAD
and of the dialogue line:
? (Y,N) ❚
Initiate the reception of data by the peripheral.
Confirm unloading of the programme. ☞
Y
Display of the message:
UNLOADING IN PROGRESS
Then, at the end of unloading, of the message:
BACKUP COMPLETED
Display of the "VERIFY PROTECTED AREA" page and the message:
VERIFY
and of the dialogue line:
? (Y,N) ❚
Verifying the programme unloaded No verification of the programme
Verify the programme (See 8.8.7.3) Refuse the verify
operation ☞
N
Continue the procedure with other programmes if necessary.
