A - 20 en-938821/2
Replacement of a numerical value by a variable
N.. G..
1
2
XE..
XL..
.....
1 - Dimension word where the numerical value is replaced by a
variable
2 - Block number
Les tableaux ci-après fournissent un récapitulatif des variables L et des paramètres E.
A.2.1 Programme L Variables
The programme variables are reset when the system is switched on or when the machine returns to M02 state.
The values of the programme variables can be defined with up to eight digits plus sign and decimal point.
L0 to L19 No restrictions in programming
L100 to L199 Loading these variables suspends preparation of the
L900 to L959 block to which they belong until the end of execution of
the previous block. Therefore, they cannot be used in a
sequence where the next blocks have to be known (e.g.
in profile geometry programming)
