Function Summary Tables
en-938821/2 A - 21
A
A.2.2 External Parameters E
Parameters E are accessible for read only or for read/write by the part programme.
A.2.2.1 Parameters in the PLC Memory
Parameters Description Value Access by the
or units part programme
E10000 to E10031 1-bit words 0 or 1 Read/write
E20000 to E20031 1-bit words 0 or 1 Read only
E20100 to E20103 State of machine inputs on machine 0 or 1 Read only
processor interrupt (IT)
E20104 to E20107 State of machine inputs on interrupt (IT) 0 or 1 Read only
from a first IT/serial line card
E20108 to E20111 State of machine inputs on interrupt (IT) 0 or 1 Read only
from a second IT/serial line card
E30000 to E30127 Long words (4 bytes) - 99999999 Read/write
à 99999999
E40000 to E40127 Long words (4 bytes) - 99999999 Read only
to 99999999
E42000 to E42127 Bytes 0 or 1 Read only
A.2.2.2 Parameters in the NC Memory
Parameters Description Value Access by the
or units part programme
E11000 Angular shift (ED) enabled 0 or 1 Read/write
(+ graphic)
E11001 Programme origin shift (G59) enabled 0 or 1 Read/write
(+ graphic)
E11003 Mirror function (G51) enabled 0 or 1 Read/write
(+ graphic)
E11005 Programming by diameter enabled 0 or 1 Read/write
(+ graphic)
E11006 Tool centre programming 0 or 1 Read/write
(+ graphic)
E11007 Spindle potentiometer enabled 0 or 1 Read/write
(+ graphic)
E11008 Execution of a complete circle 0 or 1 Read/write
(+ graphic)
E11009 Execution or not of a complete revolution 0 or 1 Read/write
on a modulo axis (+ graphic)
E11012 Cancellation of following error 0 or 1 Read/write
E11013 Gradual acceleration 0 or 1 Read/write
E11014 Addressing of the deceleration function on 0 or 1 Read/write
several blocks
E11015 Angle crossing management enabled 0 or 1 Read/write
(+ graphic)
E11016 Front or rear turret (turning) 0 or 1 Read/write
