A - 22 en-938821/2
Parameters Description Value Access by the
or units part programme
E11017 Inclined plane function enabled 0 or 1 Read only
E11018 RTCP function enabled 0 or 1 Read only
E21000 to E21255 Presence of functions 0 to 255 0 or 1 Read only
E31000 Line type for G0 in graphic display 0 to 4 Read/write
(+ graphic))
E31001 Line type for G01, G02 and G03 in 0 to 4 Read/write
graphic display (+ graphic)
E32000 Minimum execution time of an interpolation block ms Read/write
E32001 Overspeed coefficient on path in G12 1 / 1024 Read/write
E32002 Servo-control error tolerated on a circle µm Read/write
E32003 Angle crossing speed analysis angle 1/10000 degree Read/write
E32004 Chordal error µm Read/write
E32005 Number of terms of the total speed anticipation filter 1 to 14 Read/write
E33xyz PLC output addressing x = 0 to 6 Read/write
y = 0 to 9
z = 0 to 9
E34xxy 8I/8O analogue card analogue xx = 0 to 13 Write only
output addressing y = 0 to 7
E41000 Current mode number 0 to 15 Read only
E41001 Current axis group number 0 to number Read only
of groups
E41002 Number of groups in the machine 1 to 8 Read only
E41003 State of graphic machining simulation 0 to 2 Read only
E41004 Job number image 0 to 99999999 Read only
E41005 Sampling period ms Read only
E41006 Axis group position loop time constant ms Read only
E41102 Number of CNC axis groups 0 to 7 Read only
E43xyz PLC input terminal addressing x = 0 to 6 Read/write
y = 0 to 9
z = 0 to 9
E44xxy 8I/8O analogue card analogue input addressing xx = 0 to 13 Read only
y = 0 to 9
E49001 to E49128 Operation number read 1 to 128 Read only
(dynamic operators)
E50000 Current tool offset number 0 to 255 Read only
E50001 to E50255 Tool length internal unit Read/write
E51000 Current tool orientation 0 to 2 Read only
or 100 to 102
E51001 to E51255 Cutter tip radius internal unit Read/write
E52001 to E52255 Tool radius internal unit Read/write
E53001 to E53255 Tool length wear offset internal unit Read/write
E54001 to E54255 Tool radius wear offset internal unit Read/write
E55001 to E55255 Tool tip orientation (turning) 0 to 8 Read/write
