Product Presentation
2
2.1 Environment
2.1.1 NUM 1060 Series I or NUM 1060 Series II
The following diagram illustrates the links between the CNC, the machine and the peripherals for NUM 1060 Series I
and NUM 1060 Series II systems with CNC panel or LCD panel or compact panel.
INDUSTRIAL NETWORKS
• UNI-TELWAY
• MAP
• MAPWAY
Servo-drive
Motor
Movement
sensor
Additional
handwheels
PC or PS
Sensors
External
interrupts
(measurement
probes)
Actuators
Axes
PERIPHERALS
Diskette drive
Printer
SERIAL LINES
NUM 1060 Series I
or Series II CNC
MACHINE
Compact panel
Machine panel
Panel
Optional keyboard
or
or
or
∗
∗ The compact panel is incompatible with the machine panel. An optional keyboard can be connected to the compact
panel.
