Use of Peripherals
en-938821/2 C - 1
C
Appendix C Use of Peripherals
C.1 CNC / Peripheral Interconnection C - 3
C.1.1 Interconnection Diagrams C - 3
C.1.1.1 Interconnection Principles C - 3
C.1.1.2 Connection of a Peripheral to an
RS 232 Serial Line C - 4
C.1.1.3 Connection of a Peripheral to a TTL Line C - 4
C.1.1.4 Connection of a Peripheral to an RS 422,
RS 485 or RS 422 Synchronous and High
Speed Line C - 5
C.1.1.5 Connection of NUM Diskette Drive to an
RS 232 Line C - 5
C.1.1.6 Connection of NUM Diskette Drive with
Remote RS 232 Line C - 6
C.1.1.7 Connection of NUM Diskette Drive to an
RS 422 Line C - 6
C.1.1.8 Connection of NUM Diskette Drive with
Remote RS 422 Line C - 7
C.1.2 Cables C - 8
C.1.2.1 RS 232/Peripheral Device Serial
Connecting Cable C - 8
C.1.2.2 TTL/Adapter Output Cables C - 9
C.1.2.3 RS 232/Adapter Serial Connecting Cable C - 10
C.1.2.4 RS 232/NUM Drive Serial Link Cable C - 11
C.1.2.5 NUM Drive Power Cable C - 12
C.1.2.6 Remote RS 232 Line Cable on Machine
Panel or Compact Panel C - 13
C.1.2.7 NUM Drive RS 422 Serial Link Cable C - 15
C.1.2.8 Remote RS 422 Line Cable on Machine
Panel or Compact Panel C - 16
C.1.2.9 RS 422 Serial Link and High Speed Line
Cable C - 18
C.2 Connection to a Peripheral Device C - 21
C.2.1 PC Microcomputer or Compatible C - 21
C.2.1.1 Numerical Control / Microcomputer Link C - 21
C.2.1.2 Setting up the Link C - 22
C.2.2 Tape Reader/Punch C - 22
C.2.2.1 Numerical Control / Peripheral Device
Connection C - 22
C.2.2.2 Numerical Control / Peripheral Device
Connection C - 23
C.2.2.3 Setting up the Link C - 24
C.2.3 NUM Diskette Drive C - 25
C.2.4 Printer C - 25
C.2.4.1 Printers Recommended by NUM C - 25
C.2.4.2 Numerical Control / Printer Connection C - 26
C.2.4.3 Setting up the Link for Printing C - 26
C.2.4.4 Setting up the Link for Hard Copy C - 26
