3 - 18 en-938821/2
3.3.2.3 Mode Softkey Functions
Mode selection:
AUTO
Automatic mode: execution of part programme with automatic sequencing of blocks (See 5.4.3.5).
SINGLE
Single step mode: execution of part programme block by block (See 5.4.3.3).
MDI
Manual Data Input mode: manual input of a block without it being stored (See 5.3).
DRYRUN
Dry run mode: execution of part programme in dry run mode (See 5.4.3.4).
SEARCH
Sequence Number Search mode: the programme restarts at block N.. (See 5.5.1.3).
EDIT
Edit mode: modification of part programme (See 5.4.2).
TEST
Test mode: test of part programme under the operating conditions of the machine and system assembly
(See 5.4.2.6).
MANUAL
Manual mode: axes moved using axis jogs or handwheels selected by the PLC (See 5.1.1.2).
HOME
Measurement origin setting mode: acquisition of measurement origins by the system (See 5.1.2).
SHIFTS
Origin shift mode: entry of origin shifts (DAT1, DAT2 and DAT3) and scaling factor (See 5.2.1).
TL SET
Automatic tool setting mode: acquisition of tool dimensions by the system (See 5.2.2).
LOAD
Load mode: loading of part programmes (See 5.4.1) or tool dimensions (See 5.2.2.3) and selection of active
programme (See 5.4.1.2).
UNLOAD
Unload mode: unloading of part programmes or tool dimensions (See 5.6).
