Operator Panel Description
en-938821/2 3 - 17
3
3.3.2 Softkeys
The softkeys are activated using function keys F2 to F11 located below them.
3.3.2.1 Root Softkeys (Compact Panel)
Compact panel selection keys:
MODE
MODE key: gives access to the first Mode softkeys.
TOOL
TOOL key: gives access to the Tool softkeys.
JOG
JOG key: gives access to the first Jog softkeys.
3.3.2.2 Basic Softkey Functions
Display page selection:
. . / . .
DAT
- Page down (equivalent to the "Pg Dn" key on the keyboard).
- Shifts page (option available by pressing Shift): shift display page (See 4.3).
DIR.
List of stored programmes (See 4.5).
PROG.
Programme being executed (See 4.8).
INFO.
Summary of information on block (See 4.7).
L / @
List of programme variables (See 4.9.1) and equivalent addresses (See 4.9.2).
AXIS
Current point coordinates (See 4.2).
TOOLS
List of tool dimensions and wear offsets (See 4.4).
BKGND
Graphic display (See 4.6), PROCAM (See 5.7.1) and background programme operations (See 5.9).
PLC
I / O
Machine and PLC data: inputs/outputs (See 4.10).
UTIL
Access to utilities (See 8.2.2).
