3. POS
3.1 Introduction
3.1.1 System Introduction
NUUO POS, a Point of Sales Systems based on NUUO
NVR/DVR/NVDR/NVRmini/NVRmini 2, provides financial transaction’s
surveillance solution in one central system. The architecture is as below; POS
transaction data flows to NVRmini/NVRmini 2 by Ethernet. Each Cash Register
with an external receipt printer is connected by DB9 cable. The transaction
information delivered in R232 format can be converted to Ethernet through
SCB-C31A POS data capture converter.
Definition of Terms
Terms
Definition
POS Original
Data
Original data from POS. Usually with a lot of
symbols and no line feed.
POS
Transaction
Filtered result by user-defined tag-filter.
Product Specification
NUUO POS Box
SCB-C31A
Input
RS232
Output
Ethernet
DC In
DC +10V to +15V
Power consumption
500 mA
Operating
Temperature
-20 to 65℃
