4. For output pin, you can configure its duration time to control how long
output acts after it’s triggered. The duration range is 3 sec~60 sec. N/A
stands for unlimited.
5. Click the Save button.
If the box of I/O pin is unchecked, this pin won’t be shown on relative application
pages. In other words, you cannot do any setting/operation with this pin. See details
in next section.
4.3 Relative Configuration and Application
4.3.1 Record on Input Trigger
Refer to Recording Schedule / Event Setup.
4.3.2 Input and Responding Actions
Refer to I/O Box Input and Responding Action Setup.
4.3.3 I/O Control Panel in Live View
Refer to Live View Control Panel.
