86
Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
17 PCIE_CX_CPU_2N Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
17
18 GND GND BAR 18
19 PCIE_CX_CPU_3P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
19
20 PCIE_CX_CPU_3N Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
20
21 GND GND BAR 21
22 PCIE_CX_CPU_4P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
22
23 PCIE_CX_CPU_4N Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
23
24 GND GND BAR 24
