Nvidia BlueField-3 User Manual

87
Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
25 PCIE_CX_CPU_5P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
25
26 PCIE_CX_CPU_5N Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
26
27 GND GND BAR 27
28 PCIE_CX_CPU_6P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
28
29 PCIE_CX_CPU_6N Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
29
30 GND GND BAR 30
31 PCIE_X_CPU_7P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
31

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
