DGX Station Hardware Specifications
DGX Station DU-08255-001 _v4.6|97
Component Qty Description
Data storage 3 3×1.92 TB (5.76 TB total) 2.5" 6 Gb/s SATA III SSD in RAID 0 configuration
Note: Since DGX OS Desktop 4.4.0 or DGX software for Red Hat
Enterprise Linux or CentOS EL7-20.02: You can add four 1.92-
TB SSDs for data storage to give a total capacity of 13.44 TB in a
RAID 0 configuration.
OS storage 1 1.92 TB 2.5" 6 Gb/s SATA III SSD
D.3. Mechanical Specifications
Specification Value
Height 25” (639 mm)
Width 10” (256 mm)
Depth 20” (518 mm)
Gross weight 88 lbs (40 kg)
D.4. Power Specifications
Input Comments
115 - 240 VAC, 12-8A,
(50 - 60 Hz)
The DGX Station power consumption can reach 1,500 W (ambient
temperature 30°C) with all system resources under a heavy load.
Be aware of your electrical source’s power capability to avoid overloading
the circuit.
