Nvidia Jetson AGX Xavier Series User Manual

Jetson AGX Xavier Series Product DG-09840-001_v2.5 | 63
Chapter 9. Display
Jetson AGX Xavier includes three interfaces (HDMI_DP[2:0]). Each can support eDP / DP or
HDMI. See the
Jetson AGX Xavier Data Sheet for the maximum resolutions supported.
Table 9-1. Jetson AGX Xavier HDMI, eDP, and DP Pin Description
Pin # Module Pin Name SoC Signal Usage/Description
Usage on NVIDIA
Carrier Board
Direction Pin Type
H48 HDMI_DP0_TX0_N HDMI_DP0_TXDN0 DisplayPort 0 Lane 0– or HDMI Lane 2–
USB Type C Conn. J512
(via Alt Mode Switch)
Output Diff pair
H49 HDMI_DP0_TX0_P HDMI_DP0_TXDP0 DisplayPort 0 Lane 0+ or HDMI Lane 2+
G50 HDMI_DP0_TX1_N HDMI_DP0_TXDN1 DisplayPort 0 Lane 1– or HDMI Lane 1–
G51 HDMI_DP0_TX1_P HDMI_DP0_TXDP1 DisplayPort 0 Lane 1+or HDMI Lane 1+
J48
HDMI_DP0_TX2_N
HDMI_DP0_TXDN2
DisplayPort 0 Lane 2– or HDMI Lane 0–
J47 HDMI_DP0_TX2_P HDMI_DP0_TXDP2 DisplayPort 0 Lane 2+ or HDMI Lane 0+
K47 HDMI_DP0_TX3_N HDMI_DP0_TXDN3
DisplayPort 0 Lane 3– or HDMI Clk
Lane–
K46 HDMI_DP0_TX3_P HDMI_DP0_TXDP3
DisplayPort 0 Lane 3+ or HDMI Clk
Lane+
F51 DP0_AUX_CH_N DP_AUX_CH0_N DisplayPort 0 Aux– or HDMI DDC SDA
Bidir
eDP/DP Diff pair
or Open-Drain,
1.8V (3.3V
tolerant -
DDC/I2C)
F52 DP0_AUX_CH_P DP_AUX_CH0_P DisplayPort 0 Aux+ or HDMI DDC SCL
K52 DP0_HPD DP_AUX_CH0_HPD DisplayPort/HDMI 0 Hot Plug Detect Input CMOS – 1.8V
A48 HDMI_DP1_TX0_N HDMI_DP1_TXDN0 DisplayPort 1 Lane 0– or HDMI Lane 2–
USB Type C Conn. J513
(via Alt Mode Switch)
Output Diff pair
A47 HDMI_DP1_TX0_P HDMI_DP1_TXDP0 DisplayPort 1 Lane 0+ or HDMI Lane 2+
B48 HDMI_DP1_TX1_N HDMI_DP1_TXDN1 DisplayPort 1 Lane 1– or HDMI Lane 1–
B49 HDMI_DP1_TX1_P HDMI_DP1_TXDP1 DisplayPort 1 Lane 1+ or HDMI Lane 1+
D48 HDMI_DP1_TX2_N HDMI_DP1_TXDN2 DisplayPort 1 Lane 2– or HDMI Lane 0–
D49 HDMI_DP1_TX2_P HDMI_DP1_TXDP2 DisplayPort 1 Lane 2+ or HDMI Lane 0+
E51 HDMI_DP1_TX3_N HDMI_DP1_TXDN3
DisplayPort 1 Lane 3– or HDMI Clk
Lane–
E50 HDMI_DP1_TX3_P HDMI_DP1_TXDP3
DisplayPort 1 Lane 3+ or HDMI Clk
Lane+
J53 DP1_AUX_CH_N DP_AUX_CH1_N DisplayPort 1 Aux– or HDMI DDC SDA
Bidir
eDP/DP Diff pair
or Open-Drain,
1.8V (3.3V
tolerant -
DDC/I2C)
J52 DP1_AUX_CH_P DP_AUX_CH1_P DisplayPort 1 Aux+ or HDMI DDC SCL
K51
DP1_HPD
DP_AUX_CH1_HPD
DisplayPort/HDMI 1 Hot Plug Detect
Input
CMOS – 1.8V
D52 HDMI_DP2_TX0_N HDMI_DP2_TXDN0 DisplayPort 2 Lane 0– or HDMI Lane 2–
HDMI Connector Output Diff pair
D51 HDMI_DP2_TX0_P HDMI_DP2_TXDP0 DisplayPort 2 Lane 0+ or HDMI Lane 2+
B52 HDMI_DP2_TX1_N HDMI_DP2_TXDN1 DisplayPort 2 Lane 1– or HDMI Lane 1–

Nvidia Jetson AGX Xavier Series Specifications

General

GPU	512-core Volta GPU with Tensor Cores
CPU	8-core ARM v8.2 64-bit CPU, 8MB L2 + 4MB L3
Memory	32GB 256-Bit LPDDR4x | 137GB/s
Storage	32GB eMMC 5.1
DL Accelerator	2x NVDLA Engines
Vision Accelerator	7-way VLIW Vision Processor
Dimensions	105 mm x 105 mm
AI Performance	32 TOPS (INT8)
Connectivity	10/100/1000 BASE-T Ethernet
PCIe	16x PCIe Gen4
USB	USB 3.1, USB 2.0
Power	10W / 15W / 30W
Display	eDP
