Nvidia Jetson AGX Xavier Series

Video Input
Jetson AGX Xavier Series Product DG-09840-001_v2.5 | 81
Signal Name
x2 Configurations x4 Configurations
#1 #2 #3 #4 #5 #6 #1 #2 #3 #4
CSI_6_D0_P/N
Data
Data
CSI_6_D1_P/N
CSI_7_D0_P/N
CSI_7_D1_P/N
CSI_0_CLK_P/N Clk Clk
CSI_1_CLK_P/N Clk
CSI_2_CLK_P/N Clk Clk
CSI_3_CLK_P/N Clk
CSI_4_CLK_P/N Clk Clk
CSI_5_CLK_P/N
CSI_6_CLK_P/N
1
Clk Clk
CSI_7_CLK_P/N
1
Notes:
1. Each 2-lane option shown in this table can also be used for one single lane camera as well.
2. Combinations of 1, 2 and 4-lane cameras are supported, as long as any 4-lane cameras match one of
the four configurations.
