OEM PF 33 MT - Overall Dimensions; Technical Features

PF 33 MT - PF 46 MT
Transport and unpacking
EN - 5
P
H
L
Mod. L P H
PF 33 MT 41 55 78
PF 35 MT 55 71,5 84
PF 46 MT 60 85 90
Chapter 2
sizes in cm
OVERALL DIMENSIONS
2.1 - TECHNICAL FEATURES
Mod.
Outside dim.
(cm LxPxH)
Max. diameter
(ø cm)
Kw/max Max. temp. °C Net weight (Kg)
PF 33 MT 41x55x78 ø 33 cm 3,25 - 400 ~ 3N 180 119
PF 35 MT 55x71,5x84 ø 35 cm 3,40 - 400 ~ 3N 180 190
PF 46 MT 60x85x90 ø 45 cm 6,55 - 400 ~ 3N 180 240
