Ojmar OTS ADVANCE - Main Screen

OJMAR 34
APPROXIMATE
MEASUREMENTS
External
(length x width
x height)
202 x 89 x 39 mm
2.2.1 Main Screen
The main screen of the Ojmar NFC programmer displays the following information:
1. Operations with keys: See Section 2.2.2.
2. Operations with locks: See Section 2.2.3.
3. Configuration: See Section 2.2.4.
4. Date and time: Displays the date and time of the programmer. This information
will be used when recording the locks and keys.
 NOTE: The date and time are configured automatically when the programmer is
connected to the PC and synchronised with the OTS Management Software via the
events window (See Section 4.8).
5. Battery level: Displays the programmer battery level.
 NOTE: Do not switch the programmer off during charging
