Ojmar OTS ADVANCE - Infoterminal Installation; Infoterminal Mounting Guide

3_INFOTERMINAL OJMAR 47
FEATURES
MAIN FEATURES
Power supply
Power supply 12 V, 420 mA
Impact resistance
IK07
Water resistance
IP45
Operating temperature
range
-15°C / 50°C
Approximate weight
400 g
Approximate measurements
194 x 96 x 33
Reading of media
Mifare Classic 4B 1K
Mifare Classic 4B 4K
Mifare Classic 7B 1K
Mifare Classic 7B 4K
Desfire
Ultralight
Ultralight C
Certificates and safety
standards
EC Approval
3.1.3 Installation
1. To install the Infoterminal, drill 4 holes in the wall - 3 to mount the Infoterminal
and one to pass through the mains cable (see Section 3.1.1). Install the bracket
once the holes have been drilled.
