Oki B4545 MFP User Manual

Setting your terminal
53
Summer time
 2555 OK - SETUP / NETWORKS / SNTP SERVER / SUMMER
TIME
+ Select the appropriate time setting in the drop-down list: winter time,
summer time +1 or summer time +2, then validate with OK.
Remark : This menu is not displayed if the menu 212 is activated.
PC de-registering
This menu lets you delete one or more PCs connected to the terminal via the
LAN.
256 OK - SETUP / NETWORKS / DE-REG. PC
+ Select the PC that you want to delete from the list by means of the 
and  arrows, then validate with OK.
Case of connection to a domain (for instance with Windows NT,
2000 or XP)
The terminal can identify itself on the local network by using the parameters
of a user account, before it can, among others, archive documents by means
of the Scan to Disk function (refer to paragraph Scan to Disk, page 84).
Once these parameters have been filled in, they will be used by default, if you
do not declare a user name and password when using the function.
Login user name
2541 OK - SETUP / NETWORKS / DOM LOGIN / USER
+ Enter the user name for login on the local network, then validate with
OK.
Login password
2542 OK - SETUP / NETWORKS / DOM LOGIN / PASSWORD
+ Enter the password for login on the local network, then validate with OK.
Domain name
2543 OK - SETUP / NETWORKS / DOM LOGIN / DOM. NAME
+ Enter the domain name of the local network, then validate with OK.

Oki B4545 MFP Specifications

Printer

print speed	21 ppm
time to first page	13 seconds
print resolution	600 x 600 dpi
processor speed	92 MHz
duty cycle	12, 500 prints/copies per month

Fax

fax modem speed	33.6 Kbps
transmission speed	2.5 seconds
fax memory	500 pages (8 MB)

System Memory

standard imaging RAM	64 MB

Scanner

scan type	Color and Black & White
scan speed	1.8 sec./pg. Black & White; 16 sec./pg. Color
scan resolution	600 x 2400 dpi

Environmental

dimensions	17.9" x 17.5" x 20.5"
weight	32.0 lb. (14.5 kg)
power consumption	Operating 580W, Idle 20W, Power Save 15W
