Appendix A: Technical Data
A-2
Interfaces Centronics parallel
Option RS-232C serial
RS-422A serial
RS-232C/Current Loop (combined) serial
Emulations IBM ProPrinter X24/XL24 (DLL is not supported)
Epson LQ
Buffer max. 23 KByte receive buffer
Fonts/Typefaces UTL, Data processing quality
LQ: Courier, Roman, Swiss, Swiss Bold, Gothic, Prestige,
Orator, special font OCR-B1
Barcodes Code 39
UPC-A
UPC-E
EAN-8 (IAN8, JAN8)
EAN-13 (IAN13, JAN13)
Interleaved 2/5
Code 128
ZIP Code (Postnetzbarcode)
Graphic Resolution
Vertical 180, 360 points/inch
Horizontal 60, 80, 90, 120, 180, 240, 360 points/inch
Paper Feed
Top paper feed automatic single sheet insertion
Top paper feed with Cut Sheet Feeder (option)
Rear paper feed with internal Push Tractor
Bottom Paper Feed with Push Tractor (option)
Bottom Paper Feed with Pull Tractor (option)
