D-35
Appendix D: Interface Data
Connection: 3-wire
Power source receive loop: Printer
Power source send loop: Printer
IBM Asynchronous Printer Assignment of
Adapter Short-Circuit Jumper
-
+
-
+
-
+
D+ 9
D– 10
B+ 18
B– 19
GND 7
A
B
A
B
SP4
SP5
AB
SP5
CAB
AB
SP3
SP4
AB
SP2
AB
SP1
AB
SP1
Ready/Busy, XON/XOFF
Centronics Blocked Duplex
D+ 9
D– 11
B+ 18
B– 25
This connection is equivalent to circuit diagram 12. A circuit ac-
cording to diagram 13 is not possible with the IBM Asynchronous
Adapter, as the voltage supplied by this adapter’s power source is
not sufficient for the interfaces. Please refer to the section »Techni-
cal Note« earlier on in this chapter.
You can use the Centronics Blocked Duplex protocol only in combi-
nation with above circuit.
Diagram 17
This connection is equivalent
to circuit diagram 12.
