Chapter 4: Printer menu settings
4-7
Parallel I/F I-Prime
Buffer Print,
Buffer Clear, Invalid
Pin 18 +5 V, Open
Auto Feed XT Invalid, Valid
GROUP ITEM SET
Serial I/F Parity None, Even, Odd
Serial Data 7 / 8-Bits 8 Bits, 7 Bits
Protocol Ready / Busy,
X-ON / X-OFF
Diagnostic Test No, Yes
Busy Line SSD-, SSD+, DTR, RTS
Baud Rate 9600 BPS, 4800 BPS,
2400 BPS, 1200 BPS, 600 BPS,
300 BPS, 19200 BPS
DSR Signal Valid, Invalid
DTR Signal Ready on Power Up,
Ready on Select
Busy Time
200 ms, 1 sec
Auto Feed XT appears only
when Epson emulation is
selected.
GROUP ITEM SET
The menu items of the group Serial I/F only appear when a serial
interface is installed. The installation is described in the »Accesso-
ries« chapter, further technical information on interfaces is to be
found in the «Interface Data« appendix.
