Chapter 7: Accessories
7-2
Checking the items
supplied
Screws
Adjusting the length
of the feed rail
You will need a cross-head
screwdriver for this.
Check that the individual items
supplied are complete and un-
damaged. You should have re-
ceived:
• 1 feed rail
• 1 front paper stand
• 1 to 4 rear paper stands
Remove the packing material. Keep the original packing material
safe so that you can transport the sheet feeder safely at a later date if
necessary.
The metal paper feed rail enables you to fit a narrow cut sheet feed-
er onto a wide printer. All that is required is to adjust the feed rail to
the wide platen.
1. Undo and remove the
screws on the top of the feed
rail.
2. Lay the extension piece of
the rail next to the appropri-
ate holes so that they align
on the right hand side.
