Olec OLITE - Power Supply for al 85; Power Supply for al 56

94MS20 Rev. B4 3-3
Power Supply for AL 85
L1
T1
T2
L2
Power
Power
120 VAC
33RLY04
33RLY18
32TRC08
32BAL01
52FUH04
39BLO03
64MV407V04
53JKP01
62D1046-85
56FUS15
62D1047 Voltage
18
Terminal Strip
1
Output
Input
Coil Voltage
Sealed Relays
Power Relay
3Amp 250V 3AG
Slow Blow Fuse
Autoformer
Capacitor
Assembly
Safety
Interlock
Control Board
Blower
Fuse Holder
Ballast
Selection Switch
CL 85
Power Supply for AL 56
L1
T1
T2
L2
Power
Power
120 VAC
33RLY04
33RLY02
32TRC08
32BAL01
52FUH04
39BLO03
64MV407V04
53JKP01
62D2726A00
56FUS15
62D1047 Voltage
18
Terminal Strip
1
Output
Input
Coil Voltage
Sealed Relays
Power Relay
3Amp 250V 3AG
Slow Blow Fuse
Autoformer
Capacitor
Assembly
Safety
Interlock
Control Board
Blower
Fuse Holder
Ballast
Selection Switch
CL 56
