Olec OLITE - AL 56-480 Capacitor Assembly; AL 54, al 55 Capacitor Assembly

94MS20 Rev. B4 5-7
AL 56-480 Capacitor Assembly
1 2 3
WIRES
FROM
HARNESS
WIRES TO
CAPACITOR
TOP
FRONT
VIEW OF
PC BOARD
1
2
3
1
2
3
4
WIRE COLORS
1) YELLOW
2) BROWN
3) BLUE
4) BLUE WITH WHITE STRIPE
5) ORANGE
16µƒ
16µƒ
CAPACITOR ASSEMBLY #62D3083A00
10µƒ
10µƒ
5
5
2
4
1
3
AL 54, AL 55 Capacitor Assembly
DO NOT SWITCH WHILE UNIT IS ON
CAUTION
21
5
5
5
4
3
2
1
1 2 3
WIRES
FROM
HARNESS
WIRES TO
CAPACITOR
TOP
FRONT
VIEW OF
PC BOARD
1
2
3
1
2
3
4
WIRE COLORS
1) YELLOW
2) BROWN
3) BLUE
4) BLUE WITH WHITE STRIPE
5) ORANGE
6) BLACK
16µƒ
CAPACITOR ASSEMBLY PART # 62D1048
SWITCH ON CAPACITOR
MOUNTING BRACKET
4 3 2 1
REAR VIEW OF
PC BOARD
6
3
1
16µƒ
12µƒ
12µƒ
