Olec OLITE - AL 54-480, al 55-480 Capacitor Assembly; AL 53, al 50 Capacitor Assembly

5-8 94MS20 Rev. B4
AL 54-480, AL 55-480 Capacitor Assembly
DO NOT SWITCH WHILE UNIT IS ON
CAUTION
21
5
5
5
4
3
2
1
1 2 3
WIRES
FROM
HARNESS
WIRES TO
CAPACITOR
TOP
FRONT
VIEW OF
PC BOARD
1
2
3
1
2
3
4
WIRE COLORS
1) YELLOW
2) BROWN
3) BLUE
4) BLUE WITH WHITE STRIPE
5) ORANGE
6) BLACK
12µƒ
CAPACITOR ASSEMBLY PART # 62D3654A00
SWITCH ON CAPACITOR
MOUNTING BRACKET
4 3 2 1
REAR VIEW OF
PC BOARD
6
3
1
12µƒ
10µƒ
12µƒ
AL 53, AL 50 Capacitor Assembly
Capacitor Assembly 62D127
Blue / White1
Wire Colors
2
3
4
Blue
Brown
Yellow
5 Orange
3 2 1
SW
Wires to Capacitors
FRONT PCB
CAPACITOR SWITCH
Black
Blue
Yellow
REAR
PCB
64MV422-53
1234
A B C
YELLOW
1
5
5
BLUE
BLACK
4
3
2
5
NOTE: on AL 50
you MUST install
a jumper between
these two terminals.
16µƒ
12µƒ
16µƒ
12µƒ
