AL 84 Capacitor Assembly

5

WIRE COLORS

1) YELLOW

2) BROWN

3) BLUE

4) BLUE WITH WHITE STRIPE

5) ORANGE

CAPACITOR ASSEMBLY PART # 62D2652A00

12µƒ

12µƒ

10µƒ

16µƒ

2

14

3

5

5

AL 84-480 Capacitor Assembly

5

WIRE COLORS

1) YELLOW

2) BROWN

3) BLUE

4) BLUE WITH WHITE STRIPE

5) ORANGE

CAPACITOR ASSEMBLY PART # 62D3533A00

12µƒ

12µƒ

10µƒ

10µƒ

2

14

3

5

5

5
